Hot Sale New Steel 40ft Flatbed Container Cargo Semi Trailer with 15001-20000kg Payload
$10,350.00 USD
SPECIFICATIONS
Brand Name: aohai
Material: Steel
Max Payload: 15001-20000 kg
Place of Origin: Shandong, China
Type: Semi-Trailer
Use: Truck Trailer
Overall Dimension(LxWxH): |
13000x3000x1700mm（customized） |
Work Platform size (LxWxH): |
6000*3000*1200mm（customized） |
Loading Weight( KG): |
30-100 Tons（customized） |
Pull pin |
90# or 60# |
Axle: |
FUWA brand 13t x 3 axles /Other |
Main beam material: |
height is 500 mm, for thickness, upper plate is 16mm,down plate is 18mm,middle plate is 12mm. Materical:Q345B steel |
Side beam: |
16mm channel steel, Material is Q235 steel |
Landing Gear: |
standard 28ton |
Suspension system: |
Common Mechanical |
ABS |
Optional |
Tire Type and quantity: |
11.00R20, Steel Radial tire,12units |
Platform plate thickness: |
3mm Diamond plate |
Steel Spring: |
10/10/10, 90mm(Width)x13mm(Thickness) x10 Layer |
Ladder |
Manual type or Hydraulic type |
Gooseneck |
choose |
