[Main technical parameters]
Total mass (Kg):9700
Rated load (Kg):3100Curb weight (Kg):6225
Tank volume (m3):3.081
Overall dimensions (mm):7690x2250x3000
Box size (mm):××
Approach/ departure Angle(°):17/13
Front suspension/rear suspension (mm):1110/2000
Axle weight (Kg):3350/6350
Maximum speed (Km/h):100
Note
After stretch: 105 mm; Total tank volume :3.081 m3; The carrying capacity of water tank is 2150kg. Tank volume :2.15 m3; Tank size(length x width x height):1540 x 1330 x 1100(mm); The liquid capacity of type B foam tank is 950kg. Tank capacity :0.931 square meters; Tank size (length x width x height):665 x 1330 x 1100(mm); The density of class B foam solution was 1.02g/mL; Fireman's weight is 75 kg/person; Material of side protection and rear lower protection device :Q235, integral structure; Height of rear lower protective device from ground :475mm; Main special equipment has fire pump, fire cannon.
[Chassis technical parameters]
Number of shaft:2
Number of tires:6
Weelbase (mm):4475
Tire size:235/75R17.5 14PR,8.25R20 14PR
Number of leaf springs:8/10+6
Front track(mm):1680
Rear track(mm):1650
Fuel type:diesel

The vehicle includes simulation training alarm system, simulated fire fighting education training system, electric fire cause experiment system, knot rope escape experience, building fire protection equipment simulation demonstration system, LED screen display system, power supply protection and control system, screen broadcast, treble broadcast And many other systems and functions, experience a large number of projects using computer control technology, fire, fire, alarm for help, escape,ambulance,entertainment and other content readily available.

1. who are we?
We are based in Hubei, China, start from 2007,sell to Domestic Market(36.00%),Southeast Asia(22.00%),Africa(20.00%),Eastern Asia(14.00%),South Asia(4.00%),South America(2.00%),Mid East(2.00%). There are total about 101-200 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Fire Truck,Aerial Platform Truck,Road Wrecker,Garbage Truck,Road Sweeper

4. why should you buy from us not from other suppliers?
Established in 1995, Hubei Jiangnan (Dongfeng) Special Automobile Co., Ltd. is a professional manufacturer and exporter that is concerned with the design, development and production of Special Automobiles.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,Credit Card,Western Union,Cash;
Language Spoken:English,Chinese
